Universal motor/ ESC holder for multicopters

Universal  motor/ ESC holder for multicopters.
Our new motor/ESC  mounting system is designed  for heavy  payload multicopters.
Meets requirements for fixed mounting of motors together with ESC in ensuring a light weight, minimum aerodynamic resistance and maximum cooling.
Components are precision CNC technology made from aluminum and finally anodized.
The system is suitable to platforms with carbon tube arms with diameter 30mm, such as Skyhero.
Is possible to use for single or coaxial configuration.
In pictures is setup with 2x Jeti HiCopter 70A Opto ESC and 2x T-Motors MN4120  400KV in coaxial configuration.

rameno

IMG_4420-2

IMG_4443-2

IMG_4423-2

IMG_4421-2

IMG_4436-2

IMG_4419-2IMG_4418-2IMG_4416-2









Parameters:

Suitable for arm tube:
Inner diameter: 28,5mm
Outer diameter: 30mm

ESC mount:
Inner dimensions: 95x 30x26mm

Motor mount:
Mount Pattern : 4x30mm/4mm holes, center hole 15mm,thickness 2mm

weight: 67 g include screws.
